C.160.160.1000.AP
€2.88
In stock
Details
- Product Name: C.160.160.1000.AP
- Wire Diam. (mm): 1.6
- Ext. Diam. (mm): 16
- Internal Diameter (mm): 12.8
- Nr of Coils: 14.3
- Free Len. (mm): 100
- Pitch (mm): 7.84
- Shaft (mm): 12.48
- Length @max load (mm): 44.82
- Spring Rate (daN/mm): 0.181313
- Block Length(mm): 23.68
- Hole (mm): 16.4
- Buckling at length (mm): 74.09
- Weight (g): 10.342424
- Endurance: 10000000
- Grinding: 1
- Material: Music Wire
| Product Name | C.160.160.1000.AP |
|---|---|
| Wire Diam. (mm) | 1.6 |
| Ext. Diam. (mm) | 16 |
| Internal Diameter (mm) | 12.8 |
| Nr of Coils | 14.3 |
| Free Len. (mm) | 100 |
| Pitch (mm) | 7.84 |
| Shaft (mm) | 12.48 |
| Length @max load (mm) | 44.82 |
| Spring Rate (daN/mm) | 0.181313 |
| Block Length(mm) | 23.68 |
| Hole (mm) | 16.4 |
| Buckling at length (mm) | 74.09 |
| Weight (g) | 10.342424 |
| Endurance | 10000000 |
| Grinding | 1 |
| Material | Music Wire |
