C.160.160.1000.A
29.298,23 ₫
Tạm hết hàng
Details
- Product Name: C.160.160.1000.A
- Wire Diam. (mm): 1.6
- Ext. Diam. (mm): 16
- Internal Diameter (mm): 12.8
- Nr of Coils: 19.7
- Free Len. (mm): 100
- Pitch (mm): 5.45
- Shaft (mm): 12.48
- Length @max load (mm): 38.59
- Spring Rate (daN/mm): 0.126
- Block Length(mm): 32.32
- Hole (mm): 16.4
- Buckling at length (mm): 74.09
- Weight (g): 14.158257
- Endurance: 10000000
- Grinding: Yes
- Material: Music Wire
| Product Name | C.160.160.1000.A |
|---|---|
| Wire Diam. (mm) | 1.6 |
| Ext. Diam. (mm) | 16 |
| Internal Diameter (mm) | 12.8 |
| Nr of Coils | 19.7 |
| Free Len. (mm) | 100 |
| Pitch (mm) | 5.45 |
| Shaft (mm) | 12.48 |
| Length @max load (mm) | 38.59 |
| Spring Rate (daN/mm) | 0.126 |
| Block Length(mm) | 32.32 |
| Hole (mm) | 16.4 |
| Buckling at length (mm) | 74.09 |
| Weight (g) | 14.158257 |
| Endurance | 10000000 |
| Grinding | Yes |
| Material | Music Wire |
